Alumina 4N Resin

Alumina 4N Resin brings high-purity technical ceramic 3D printing to the world’s most affordable ceramic ecosystem. As a Form X material, it features an advanced workflow tailored for expert users, allowing you to manufacture high-density ceramic components without expensive tooling.
By reducing production costs and lead times while expanding design freedom, Alumina 4N delivers exceptional performance in extreme environments. The resulting parts are highly thermal-resistant, hard, abrasion-resistant, mechanically strong, and chemically inert.

Why Choose Alumina 4N Resin
Alumina 4N Resin is a 99.99% pure alumina technical ceramic with 98.6% relative density, and exceptional thermal, mechanical, and conductive properties — comparable to traditionally manufactured alumina (Al2O3).
Ceramic 3D Printing Made Accessible

The most affordable and easiest-to-use ceramic 3D printer in the world. Over 10x lower starting price compared to the leading alternatives.

Unprecedented Design Freedom
Fabricate ceramic components with intricate internal channels, latticed structures, and complex geometries that are impossible with traditionally manufactured alumina. Optimize parts without sacrificing quality or performance.
Shortened Turnaround Time and Reduced Costs
Ditch expensive tooling and molds for reduced production costs and a quicker end-to-end process for a faster development cycle overall.
Extreme Performance
Reliable in extreme applications with a max working temperature of 1500°C, maintaining an impressive flexural strength of over 400 MPa in addition to resisting compression and deflection with a modulus of 380 GPa.
Applications
Alumina 4N Resin is a cost and time-effective solution for fabricating high-performance parts for extreme environments. Parts printed in Alumina 4N Resin serve as good heat and electrical insulators, heavy-duty tools, as well as chemically resistant and wear-resistant components. They are used in industries such as defense, manufacturing, chemicals, and automotive.
Consider Alumina 4N Resin for:
  • High voltage components: enclosures, connector housings and covers, terminal blocks
  • Chemical resistance: manifold pipes, mixing blades and pipes
  • Thermal protection: spark plug insulators, electrical mounting, insulating housings or tubes
  • Foundry tools for metal casting: cores, crucibles, gating, sprues, mixing tools, thermocouple sheaths, metal filters
Material Properties

Additional information

Type

Ceramic Resin
Compatibility

Form 4 / Form 3
Features

High purity ceramic, sintering capable
