ULTEM 9085
Price range: ₱12,480.00 through ₱24,950.00
The Intamsys PEI 9085 (polyetherimide) is an FAA-approved amorphous thermoplastic that meets stringent aerospace industry requirements. The material achieves tensile strength values of 54–71.6 MPa and tensile modulus of 2050–2200 MPa, according to standardized testing from IEMAI3D technical documentation. PEI 9085 demonstrates flame retardancy rated UL 94 V-0 at 1.5mm thickness and complies with FAR 25.853 and OSU 65/65 standards for flame, smoke, and toxicity properties.
The material exhibits a glass transition temperature of 186 °C and deflection temperature of 158 °C at 0.45 MPa, according to DSC testing from IEMAI3D thermal analysis. PEI 9085 maintains dimensional stability with low smoke emission characteristics and excellent chemical resistance to automotive fluids, alcohols, and various solvents.
The Intamsys PEI 9085 serves aerospace applications including aircraft interior components, ductwork, and electrical enclosures requiring FST compliance, according to NCAMP certification research. Transportation applications encompass automotive interior parts, rail components, and marine structural elements that demand flame retardancy and mechanical durability. Electronics applications feature enclosures and structural frames protecting sensitive components through vibration attenuation properties, according to Zortrax aerospace applications analysis.
The Intamsys PEI 9085 1.75 mm support filament is sold in 500 g / 1 kg spools. It comes vacuum-sealed with desiccant.
Additional information
| Filament Diameter | 1.75 mm |
|---|---|
| Chamber temperature | 80–150 °C |
| Density | 1.34 g/cm³ |
| FAA compliance | FAR 25.853, OSU 65/65 |
| Filament weight | 500 g / 1 kg |
| Flexural modulus | 2170–2500 MPa |
| Flexural strength | 90–115.1 MPa |
| Glass transition temperature | 186 °C |
| Heat deflection temperature | 158 °C at 0.45 MPa |
| Nozzle temperature | 330–390 °C |
| Print bed temperature | 110–160 °C |
