Flame Retardant Resin
Price range: ₱20,707.00 through ₱21,538.00
Flame Retardant Resin
Flame Retardant (FR) Resin is a specialty, UL 94 Blue Card certified material engineered for self-extinguishing, halogen-free parts with favorable flame, smoke, and toxicity (FST) ratings. It enables the efficient 3D printing of stiff, creep-resistant components designed for long-term reliability. Formulated to withstand high temperatures and ignition sources, FR Resin is ideal for demanding applications in both indoor and industrial environments.
Why Choose Flame Retardant (FR) Resin
Accelerate your time to market by bypassing the upfront costs and design constraints of traditional manufacturing. With ultra-high resolution (25 $\mu$m XY) and isotropic properties, this technology delivers highly detailed parts with unlimited geometric freedom. Whether you need a single prototype or a production run of up to 1,000 parts, you can print on demand, anytime.
Certified Flame Retardant
Produce certified flame retardant, UL 94 V-0 and FAR-rated 3D printed parts that meet necessary certification requirements for enduring hazardous environments.
Look and Feel of Injection Molded Parts
Fabricate plastic parts with exceptional surface finish far superior to other fabrication methods such as FDM 3D printing.
Heat and Creep Resistant
Parts will perform well long-term in indoor and industrial environments with high temperatures or ignition sources.
Stiff and Functional
Produce stiff and functional parts with a 2.9GPa modulus that can handle post-fabrication operations such as tapping, trimming, and drilling.
Applications
Flame Retardant (FR) Resin is a cost and time-effective solution for fabricating self-extinguishing parts.
FR Resin is ideal for:
- Interior parts in airplanes, automobiles, and railways with excellent surface finish
- Protective and internal consumer or medical electronics components
- Custom jigs, fixtures, and replacement parts for industrial environments with high temperatures or ignition sources
Additional information
| Volume | 0.84L |
|---|---|
| Heat Deflection Temperature 0.45 MPa | 94ºC |
| Heat Deflection Temperature 1.8 MPa | 71ºC |
| Tensile Modulus | 2.9 GPa |
| Ultimate Tensile Strength | 38.5 MPa |
| Elongation at Break | 9.4% |
