Flashforge Creator 4

Flashforge Creator 4

Creator 4 features extruders that work independently, allowing the printer to create dual extrusion parts accurately and beautifully. This also allows the printer to print two objects simultaneously in Duplicate Mode or Mirror Mode.

Category:

Brand:

flashforge-logo

Technologies:

Flashforge Creator 4

Industries:

Flashforge Creator 4

Applications:

Flashforge Creator 4

Category:

 New
 Includes Warranty
 Local Technical Support
 Pre-Order

IDEX System: Dual extruders working independently

Creator 4 features extruders that work independently, allowing the printer to create dual extrusion parts accurately and beautifully. This also allows the printer to print two objects simultaneously in Duplicate Mode or Mirror Mode. This means that the two extruders are working simultaneously and independently to double your outputs! Creator 4 is a step closer for mass production!

3 extruder options support multiple filaments

Creator 4 sports the ability to quickly change between nozzles and print heads. Currently, the Creator 4 has 3 types that can greatly improve the accuracy and quality of prints based on filament material:

  • Extruder-F for flexible filament.
  • Extruder-HT for engineering filament.
  • Extruder-HS for carbon fiber composite.



Extruder-F

Printing for 85A Flexible Filament

Printing Speed:

  • 100mm/s

Filament Diameter:

  • 2.85mm

Printing Temperature:

  • 265℃

Supported Filament:

  • TPU85A / TPE / TPB / TPC

Extruder-HT

Printing for Engineering Filament

Printing Speed:

  • 200mm/s

Filament Diameter:

  • 1.75mm

Printing Temperature:

  • 320℃

Supported Filament:

  • PC / PA / PP / PETG / ASA / ABS / PLA / PC-ABS / PAHT

Extruder-HS

Printing for Carbon Fiber Composite

Printing Speed:

  • 150mm/s

Filament Diameter:

  • 1.75mm

Printing Temperature:

  • 360℃

Supported Filament:

  • PACF / PET-CF / PP-CF / PA-GF / PC-ABS / PP-GF / PPS-CF / PPS

Temperature in the chamber ensures good printout quality

The advanced thermal-control system of Creator 4 keeps the print chamber at 65℃, which effectively reduces model shrinkage, warping at corners, and furnish breakage. Creator 4 ensures good printout quality, good printing precision and improves print success rate a lot.

Large build volume; Affordable price

  • Printing size: 400mm*350mm*500mm;
  • Up o 500mm in vertical height meets most manufacturer's printing needs.

High-precision printing

  • Linear-rail leadscrew stepping along X and Y axes greatly improves motion stability, hence better printing precision.
  • Brand new S-type motion control system achieves smoother start and stop, precise positioning of the nozzle, and wonderful printing details.
  • CNC structure keeps machine stable and less shake when it's working.

Friendly and intelligent filament management system

Different filaments can be automatically adjusted to different preheating temperatures in the chamber, achieving higher success rate of printing. When finishing printing, the chamber temperature can be adjusted automatically for model cooling down. Quite friendly system design for next print!

If you don't want the automatically set temperature, you can customize it yourself!



Filament Drying Station

The Filament Drying Station is a multifunctional product that integrates 3D printing equipment placement, storage and drying of 3D printing filaments, and the movable shelf function. As a matching product of Creator 4, it aims to restore the properties of the wet filaments and solve the problem of the drying and storage of filaments;

As its size matches the size of Creator 4, it can be used as an elevated shelf; With casters equipped, it is convenient for movement and switching the working area at will.

Improve the whole process of 3D printing and control the printing quality

The Filament Drying Station improves the whole process of 3D printing, ensures the stable use of filaments throughout the whole workflow, prolongs the normal running time of your printer to the maximum extent, and guarantees the printing quality.





Service Organization

Small-batch part production

Promote the Productivity Reform

The lampshade produced by the Biomass Science and Technology Museum of Hangzhou Research Institute of Chemical Industry was well received once it came into the market.

Type / Creator 4-A Creator 4-S
Extruder Extruder-F (optional) Extruder-HT Extruder-HS
Filament TPU85A / TPE / TPB / TPC PLA / PETG / PC-ABS / PAHT / ABS /ASA / PP / PA / PC PACF / PET-CF / PP-CF / PA-GF / PC-ABS / PP-GF / PPS-CF / PPS
Extruder type IDEX IDEX IDEX
Nozzle diameter 0.4mm 0.4(0.6/0.8)mm 0.4(0.6/0.8)mm
Extruder temperature 265℃ 320℃ 360℃
Maximum chamber heating temperature 65℃ 65℃ 65℃
Printing volume 400*350*500mm 400*350*500mm 400*350*500mm
Printing speed 100mm/s 200mm/s 150mm/s
Maximum platform heating temperature 130℃ 130℃ 130℃
Touch screen size 7-inch 7-inch 7-inch
