Material Characteristics & Performance

• Heat Resistance: Heat Deflection Temperature (0.45 MPa) around 252–253 °C

• Dimensional Stability: Low warping and shrinkage thanks to warp-free technology

• Flame Retardancy: UL94 V0 (1.5 mm thickness)

• Chemical Resistance: Withstands acids, alkalis, fuels, solvents

• Moisture Insensitivity: Prints well even on open-bed printers

• Mechanical Properties (printed specimens):

  • Dry Young’s Modulus: ~5314 MPa

  • Flexural Modulus: ~4647 MPa

  • Tensile Strength (Z‑axis): ~32 MPa

  • Charpy Notched Impact: ~5.3 kJ/m²

• Additional Thermal Metrics:

  • Glass Transition ≈ 98 °C; Vicat Softening ≈ 268 °C; Flex HDT at 1.8 MPa ≈ 133 °C

• Density: ~1.29 g/cm³

Printing Recommendations
