Makerbot Sketch Large
Print large classroom projects without compromising on size. 15 available seats for student certification and 1 seat for educator certification. Sketch Large’s combined build volume is 205inch with 3 spools.
Print Bigger and Bolder
Streamlining printing for the whole classroom
ISTE-Certified self-paced 3D printer training for both teachers and students
Makerbot Sketch Large
Print large classroom projects without compromising on size. 15 available seats for student certification and 1 seat for educator certification. Sketch Large’s combined build volume is 205inch with 3 spools.
Print Bigger and Bolder
Streamlining printing for the whole classroom
ISTE-Certified self-paced 3D printer training for both teachers and students
Print large classroom projects without compromising on size. 15 available seats for student certification and 1 seat for educator certification. Sketch Large's combined build volume is 205inch with 3 spools.
Print bigger and bolder
Explore 3D printing on a bigger stage, enable students to design bigger and unhindered on an easy-to-use printer.
Maximum build volume:
220mm x 200mm x 250mm
[8.66in x 7.87in x 9.84in]
Streamlining printing for the whole classroom
Join the only 3D printer platform that has been helping educators pioneer 3D printing in the classroom for over 10 years.
Classroom 3D Printing made easy
Tap into a 3D printing software with built in features that make 3D printing in the classroom easier than ever before.
Plus every feature of the Sketch large
Enclosed printer with particulate filter
Place your printer anywhere in the classroom without worrying about curious hands and print with peace of mind with a particulate filter preinstalled in each printer.
Flexible heated build plate
Heated build plate for secure, successful printing and a flexible surface to make removing finished prints a breeze.
Cloud-based 3D printer software
No project is too big or small for Sketch, choose the build volume that is right for your classroom.
Replaceable extruder
Optimized for PLA and Tough PLA 3D printing, Sketch 3D printer includes a replaceable extruder with a 0.4 mm nozzle.
Full color touchsreen
Start, monitor and pause students’ prints with an intuitive interface
On board camera
With an onboard camera to make monitoring prints possible from anywhere.
| General Specifications | |
|---|---|
| Print Technology | Fused Deposition Modelling (FDM) |
| Build Volume | 220mm x 200mm x 250mm (8.66 x 7.87 x 9.84 inches) |
| Layer Resolution | 100-400 microns (0.0039 – 0.0157 inches) Print mode tuned for 200 microns |
| Material Diameter | 1.75 mm (0.069 inches) |
| Material Compatibility | MakerBot Sketch PLA Material |
| Extruder Compatibility | MakerBot Sketch Extruder |
| Nozzle Diameter | 0.4 mm (0.015 inches) |
| Print File Type | .MAKERBOT |
| Temperature | |
| Ambient Operating Temperature | 15-30°C (59-86°F) |
| Storage Temperature | 0-55°C (32-131°F) |
| Size & Weight | |
| Product Dimensions | 547mm (H) x 535mm (W) x 470mm (D) 21.54in (H) x 21.07in (W) x 18.5in (D) |
| Shipping Box | 675mm (H) x 569mm (W) x 591mm (D) 26.57in (H) x 22.4in (W) X 23.27in (D) |
| Product Weight | 23.2 kg (51.15 lb) |
| Shipping Weight | 32.5 kg (71.65 lb) |
| Mechanical | |
| Build Surface | Grip Surface |
| Build Plate Leveling | Heated with removable flexible build surface |
| Safety & Compliance | |
| Safety | Fully enclosed, Particulate Filter UL, CE, FCC IEC/ EN/ UL60950-1, IEC/ EN/UL 62368-1 |
| Software | |
| Software Bundle | MakerBot CloudPrint |
| Supported File Types | MakerBot (.makerbot), STL (.stl), SolidWorks (.sldprt, .sldasm), Inventor (.ipt, .iam), IGES (.iges, .igs), STEP AP203/214 (.step, .stp) |
| Operating Systems | Windows (7, 10), Mac OS X (10.12+) Note: Does not support Mac Catalina |
| Electrical | |
| Power Requirements | 100-240 V, 50-60 HZ, 2.7-1.3A |
| Connectivity | |
| Connectivity | USB, Ethernet, Wifi |
| Camera | |
| Camera Resolution | 2 Megapixels |
